Multi-jet Vane Wheel Wet-dial Cold Or Hot Water Meter
Measuring the total volume of cold (hot)water passing through the pipeline. This type of water meter can be used for a remote reading transmission system as equipped with a built-in-sensor.
By setting a special flow guiding structure at the inlet, it "disperses" a single water flow into multiple water streams, which impact the impeller more evenly from different angles, thereby achieving high measurement accuracy and stability over a wider flow range.
Description
LXSG DN15-50 Multi-jet Vane wheel dry-dial Water Meter
Product features/advantages
- Multi-jet, dry-dial; Magnetic drive;
- Vacuum sealed register ensures the dial keep free from fog and frost, Keep the reading clear in a long term service;
- Removable measuring unit,easy installation and maintenance, Anti-magnetic function;
- Measuring high flow rate with low head loss,inner and outside adjustment is optional;
- Remote transmission device can be added upon request:such as Reed Swith or Hall, Pulse Output
- Technical data conform to lSO4064 standard.
Standard: GB/T 778; ISO4064
Water meter body material：gray iron, ductile iron, stainless steel, plastic
Verification level standard：R50; R80; R100; R125; R160; R200
Working condition
- Water temperature: T30 T50
- Water pressure class: MAP16; MAP10 (PLASTIC BODY)
- Pressure-loss class: ∆p63
Maximum permissible error
(1)From minimum flow-rate(Q1)inclusive to transitional flow-rate(Q2)exclusive±5%.
(2)From transitional flow-rate(Q2) to overload flow rate(Q4)±2%(Hot water meter ±3%)
Models and specification
|
Model |
Size |
Length |
Broad |
Height |
Connection threads |
|
|
mm |
D |
R |
||||
|
LXSG-15 |
1/2" |
165 |
98 |
116 |
G3/4 |
R1/2 |
|
LXSG-20 |
3/4" |
195 |
98 |
117 |
G1 |
R3/4 |
|
LXSG-25 |
1" |
260 |
104 |
124 |
G1¼ |
R1 |
|
LXSG-32 |
1/4" |
260 |
104 |
124 |
G1½ |
R1¼ |
|
LXSG-40 |
1/2" |
300 |
125 |
162 |
G2 |
R1½ |
|
LXSG-50 |
2" |
300 |
125 |
162 |
G2½ |
R2 |
|
280 |
165 |
188 |
Flange connect ISO |
|||
|
MAIN TECHNICAL SPECIFICATIONS
|
||||||
|
Type |
Size |
Q4 OverLoad Flow |
Q3 |
Q2 |
Q1 Min.Flow |
Maximum Reading |
|
m³/h |
m³ |
|||||
|
LXSG-15 |
1/2" |
3.125 |
2.5 |
0.04 |
0.025 |
99,999 |
|
LXSG-20 |
3/4" |
5 |
4 |
0.064 |
0.04 |
99,999 |
|
LXSG-25 |
1" |
7.875 |
6.3 |
0.1008 |
0.063 |
99,999 |
|
LXSG-32 |
1¼" |
12.5 |
10 |
0.16 |
0.1 |
99,999 |
|
LXSG-40 |
1½" |
20 |
16 |
0.256 |
0.16 |
99,999 |
|
LXSG-50 |
2" |
31.25 |
25 |
0.4 |
0.25 |
99,999 |
Water meter explosive view
FAQ
Products and Services
1. Q: What types of water meters does your factory mainly produce?
A: We focus on the research and development and manufacturing of various types of water meters. Our main product lines include: large-diameter water meters, small-diameter water meters, smart water meters, valves and accessories.
We provide a full range of solutions to meet the different metering needs of households, commercial buildings, industrial parks, and urban and rural water supply networks.
2. Q: What is your product warranty policy?
A: We have full confidence in every water meter we produce. All products enjoy a one-year quality guarantee from the date of manufacture. Under normal use and in accordance with installation specifications, we will provide free repair or replacement for malfunctions caused by defects in materials or manufacturing processes.
3. Q: How are technical support and after-sales service provided?
A: We are committed to providing full lifecycle customer support:
- Pre-sales consultation: Providing professional selection guidance, solution design, and technical Q&A.
- In-sales support: Providing clear product installation manuals, wiring diagrams, or on-site installation guidance (depending on the project).
- After-sales response: Establishing a dedicated after-sales service hotline email [hytten@hyttenmeter.com]. For reported issues, we promise to respond within 1 hour and provide solutions such as remote diagnostics, sending parts, or arranging on-site technical support, depending on the urgency of the issue.
- Value-added services: For smart water meter projects, we can provide data docking and debugging assistance and system operation and maintenance training.
